Fault tolerance

Configure per-node timeouts, retries, and error handlers in LangGraph.

When a node fails—from a slow external API, a transient network error, or an unhandled exception—LangGraph gives you three composable mechanisms to respond:

• Retries — automatically re-run failed attempts based on exception type and backoff settings
• Timeouts — cap how long a single attempt may run
• Error handling — run a recovery function after all retries are exhausted

These compose in a fixed order: when a node attempt raises any exception (including NodeTimeoutError from a timeout), the retry policy decides whether to retry. Only after retries are exhausted does the error handler run.

For stopping a run cleanly at a superstep boundary and resuming later, see Graceful shutdown.

Per-node timeouts and node-level error handlers require langgraph>=1.2.

Retries

A retry policy automatically re-runs a failed node attempt based on exception type and backoff settings. Pass retry_policy= to add_node:

from langgraph.types import RetryPolicy

builder.add_node(
    "call_api",
    call_api,
    retry_policy=RetryPolicy(max_attempts=3),
)

Default behavior

By default, retry_on uses default_retry_on, which retries on any exception except the following (and their subclasses):

• ValueError
• TypeError
• ArithmeticError
• ImportError
• LookupError
• NameError
• SyntaxError
• RuntimeError
• ReferenceError
• StopIteration
• StopAsyncIteration
• OSError

For exceptions from popular HTTP libraries such as requests and httpx, it only retries on 5xx status codes. NodeTimeoutError is retryable by default.

Parameters

Parameter	Type	Default	Description
max_attempts	int	3	Maximum number of attempts, including the first.
initial_interval	float	0.5	Seconds before the first retry.
backoff_factor	float	2.0	Multiplier applied to the interval after each retry.
max_interval	float	128.0	Maximum seconds between retries.
jitter	bool	True	Add random jitter to the interval.
retry_on	type[Exception] | Sequence[type[Exception]] | Callable[[Exception], bool]	default_retry_on	Exceptions to retry on, or a callable returning True for retryable exceptions.

Custom retry logic

Pass a callable or exception type to retry_on. Import default_retry_on to extend the default behavior:

from langgraph.types import RetryPolicy, default_retry_on

def custom_retry_on(exc: BaseException) -> bool:
    if isinstance(exc, MyCustomError):
        return False
    return default_retry_on(exc)

builder.add_node(
    "call_api",
    call_api,
    retry_policy=RetryPolicy(max_attempts=3, retry_on=custom_retry_on),
)

Inspect retry state

Use runtime.execution_info inside a node to inspect the current attempt number. This is useful for switching to a fallback when the primary call keeps failing:

from langgraph.graph import StateGraph, START, END
from langgraph.runtime import Runtime
from langgraph.types import RetryPolicy
from typing_extensions import TypedDict

class State(TypedDict):
    result: str

def my_node(state: State, runtime: Runtime) -> State:
    if runtime.execution_info.node_attempt > 1:
        return {"result": call_fallback_api()}
    return {"result": call_primary_api()}

builder = StateGraph(State)
builder.add_node("my_node", my_node, retry_policy=RetryPolicy(max_attempts=3))
builder.add_edge(START, "my_node")
builder.add_edge("my_node", END)

execution_info exposes the following fields:

Attribute	Type	Description
node_attempt	int	Current attempt number (1-indexed). 1 on the first try, 2 on the first retry, etc.
node_first_attempt_time	float | None	Unix timestamp of when the first attempt started. Constant across retries.
thread_id	str | None	Thread ID for the current execution. None without a checkpointer.
run_id	str | None	Run ID for the current execution. None when not provided in config.
checkpoint_id	str	Checkpoint ID for the current execution.
task_id	str	Task ID for the current execution.

execution_info is available even without a retry policy—node_attempt defaults to 1.

Timeouts

Requires langgraph>=1.2.

The timeout= parameter on add_node caps how long a single node attempt may run. Pass a number (seconds), a timedelta, or a TimeoutPolicy for separate run and idle limits:

from datetime import timedelta
from langgraph.types import TimeoutPolicy

# Simple wall-clock cap
builder.add_node("call_model", call_model, timeout=60)
builder.add_node("call_model", call_model, timeout=timedelta(minutes=2))

# Separate run and idle limits
builder.add_node(
    "call_model",
    call_model,
    timeout=TimeoutPolicy(run_timeout=120, idle_timeout=30),
)

Node timeouts only apply to async nodes. Sync nodes with a timeout are rejected at compile time. To wrap blocking I/O, use asyncio.to_thread inside an async node.

Run timeout

run_timeout is a hard wall-clock cap on a single attempt. It is never refreshed, regardless of node activity:

from langgraph.types import TimeoutPolicy

builder.add_node(
    "call_model",
    call_model,
    timeout=TimeoutPolicy(run_timeout=120),
)

When the limit is exceeded, LangGraph raises NodeTimeoutError, clears any writes from the failed attempt, and lets the retry policy decide whether to retry.

Idle timeout

idle_timeout is a progress-resetting cap. It fires only when the node stops making observable progress for the specified duration—unlike run_timeout, the clock resets whenever the node produces a progress signal:

builder.add_node(
    "call_model",
    call_model,
    timeout=TimeoutPolicy(idle_timeout=30),
)

You can set run_timeout and idle_timeout together. Whichever fires first cancels the attempt.

Progress signals

Under the default refresh_on="auto", the idle clock resets on any of the following:

• State writes via CONFIG_KEY_SEND
• Stream output (yielded async stream chunks)
• Child-task scheduling
• Runtime stream-writer calls
• Any LangChain callback event from the node or its descendants (LLM tokens, tool calls, chain start/end, etc.)

Heartbeat mode

Set refresh_on="heartbeat" to narrow the refresh source to explicit runtime.heartbeat() calls only. This is useful when you want a strict idle definition that isn’t reset by chatty subordinates:

builder.add_node(
    "call_model",
    call_model,
    timeout=TimeoutPolicy(idle_timeout=30, refresh_on="heartbeat"),
)

Manual heartbeats

For long-running async work that doesn’t naturally emit progress signals, call runtime.heartbeat() to manually reset the idle clock:

from langgraph.graph import StateGraph, START, END
from langgraph.runtime import Runtime
from langgraph.types import TimeoutPolicy
from typing_extensions import TypedDict

class State(TypedDict):
    result: str

async def long_running_node(state: State, runtime: Runtime) -> State:
    for batch in fetch_batches():
        process(batch)
        runtime.heartbeat()
    return {"result": "done"}

builder = StateGraph(State)
builder.add_node(
    "long_running_node",
    long_running_node,
    timeout=TimeoutPolicy(idle_timeout=30, refresh_on="heartbeat"),
)
builder.add_edge(START, "long_running_node")
builder.add_edge("long_running_node", END)

runtime.heartbeat() is a no-op outside an idle-timed attempt, so you can call it unconditionally.

NodeTimeoutError

When a timeout fires, LangGraph raises NodeTimeoutError with structured context about which limit was hit:

Attribute	Type	Description
node	str	Name of the node whose execution timed out.
elapsed	float	Seconds elapsed before the timeout fired.
kind	Literal["idle", "run"]	Which timeout fired.
idle_timeout	float | None	The configured idle timeout (seconds), if any.
run_timeout	float | None	The configured run timeout (seconds), if any.

NodeTimeoutError is retryable by default. Combining timeout= with retry_policy= works out of the box—the timeout clock resets on each new attempt, and writes from a timed-out attempt are cleared before the next retry:

from langgraph.types import RetryPolicy, TimeoutPolicy

builder.add_node(
    "call_model",
    call_model,
    timeout=TimeoutPolicy(idle_timeout=30),
    retry_policy=RetryPolicy(max_attempts=3),
)

Dynamic timeouts with Send

When using Send to dispatch nodes dynamically (for example, in map-reduce patterns), you can pass a timeout= directly on the Send to override the target node’s static timeout for that specific push:

from langgraph.types import Send, TimeoutPolicy

def fan_out(state: OverallState):
    return [
        Send("process_item", {"item": item}, timeout=TimeoutPolicy(idle_timeout=15))
        for item in state["items"]
    ]

If timeout= is omitted on the Send, the target node’s timeout (set at add_node time) applies. This lets you set a default timeout on the node and tighten it for individual calls.

Error handling

Requires langgraph>=1.2.

An error handler runs after a node fails and all retries are exhausted. It receives the current state and can update it or route to a different node using Command. This is useful for compensation flows (Saga patterns) where you want to recover gracefully rather than abort the entire graph.

Pass error_handler= to add_node:

from langgraph.errors import NodeError
from langgraph.types import Command, RetryPolicy
from langgraph.graph import StateGraph, START
from typing_extensions import TypedDict

class State(TypedDict):
    status: str

def charge_payment(state: State) -> State:
    raise RuntimeError("payment gateway timeout")

def payment_error_handler(state: State, error: NodeError) -> Command:
    return Command(
        update={"status": f"compensated: {error.error}"},
        goto="finalize",
    )

def finalize(state: State) -> State:
    return state

graph = (
    StateGraph(State)
    .add_node(
        "charge_payment",
        charge_payment,
        retry_policy=RetryPolicy(max_attempts=3, retry_on=ConnectionError),
        error_handler=payment_error_handler,
    )
    .add_node("finalize", finalize)
    .add_edge(START, "charge_payment")
    .compile()
)

The handler fires only after retry_policy is exhausted, or immediately if no retry policy is configured. The retry policy and the error handler stay decoupled: configure when to retry and when to compensate independently.

NodeError

Error handlers receive failure context through a typed error: NodeError parameter, injected by type annotation (the same pattern as runtime: Runtime):

from langgraph.errors import NodeError

def my_handler(state: State, error: NodeError) -> Command:
    print(f"Node {error.node} failed with: {error.error}")
    return Command(update={"status": "recovered"}, goto="next_step")

NodeError is a frozen dataclass with two fields:

Attribute	Type	Description
node	str	Name of the node whose execution failed.
error	BaseException	The exception raised by the failed node.

The error: NodeError parameter is opt-in. Handlers that don’t need failure context can use simpler signatures like (state) or (state, runtime).

Route with Command

Error handlers can return a Command to update state and route to a specific node, enabling Saga / compensation patterns:

from langgraph.errors import NodeError
from langgraph.types import Command, RetryPolicy
from langgraph.graph import StateGraph, START
from typing_extensions import TypedDict

class State(TypedDict):
    status: str

def reserve_inventory(state: State) -> State:
    return {"status": "reserved"}

def charge_payment(state: State) -> State:
    raise RuntimeError("payment timeout")

def payment_error_handler(state: State, error: NodeError) -> Command:
    return Command(
        update={"status": f"compensated_after_{error.node}: {error.error}"},
        goto="finalize",
    )

def finalize(state: State) -> State:
    return state

graph = (
    StateGraph(State)
    .add_node("reserve_inventory", reserve_inventory)
    .add_node(
        "charge_payment",
        charge_payment,
        retry_policy=RetryPolicy(max_attempts=3, retry_on=ConnectionError),
        error_handler=payment_error_handler,
    )
    .add_node("finalize", finalize)
    .add_edge(START, "reserve_inventory")
    .add_edge("reserve_inventory", "charge_payment")
    .compile()
)

charge_payment retries on ConnectionError up to 3 times. If retries are exhausted (or the error isn’t a ConnectionError), the handler compensates by updating state and routing to finalize instead of aborting the graph.

Resume-safe failures

Failure provenance is checkpointed. If the graph is interrupted or the process crashes after a node fails but before the handler completes, the handler sees the same NodeError context when the graph resumes from its checkpoint.

The transition is atomic at the superstep boundary. This is the part that’s painful to get right outside a workflow engine. When the original node fails, its ERROR write is committed to the checkpoint, and the handler task is scheduled as a new task in the same step.

Handler crashes resume safely too. If the handler itself raises—or the host process crashes mid-handler—and a checkpointer is configured, resuming the run re-schedules the handler, not the original failing node. Once a run enters the recovery phase, it stays there.

Behavior with interrupt()

interrupt() raised inside a node is not routed to the error handler. Interrupts use the GraphBubbleUp mechanism to pause graph execution for human-in-the-loop workflows, bypassing both retry policies and error handlers. The graph pauses as usual.

Subgraph failures

If a node wraps a subgraph and the subgraph raises an unhandled exception, that exception surfaces to the parent node. If the parent node has an error_handler, the handler fires with the subgraph’s exception in error.error.

Graph-wide defaults

Requires langgraph>=1.2.

Use set_node_defaults on StateGraph to configure retry, timeout, cache, and error-handler policies once for every node in the graph. Per-node values passed to add_node always override the defaults, and the defaults are applied at compile() time:

from langgraph.types import RetryPolicy, TimeoutPolicy

graph = (
    StateGraph(State)
    .set_node_defaults(
        retry_policy=RetryPolicy(max_attempts=3),
        error_handler=my_fallback_handler,
        timeout=TimeoutPolicy(run_timeout=30),
    )
    .add_node("a", node_a)
    .add_node("b", node_b, retry_policy=custom_retry)  # overrides default
    .add_edge(START, "a")
    .compile()
)

set_node_defaults is a fluent builder method that returns the same StateGraph, so it chains naturally with add_node, add_edge, and compile. Defaults are not inherited by subgraphs.

Supported defaults

set_node_defaults kwarg	Fallback for add_node kwarg	Applies to error-handler nodes?
retry_policy	retry_policy	Yes—a stuck handler is retried like any other node.
timeout	timeout	Yes—a stuck handler is cancelled like any other node.
cache_policy	cache_policy	No—caching handler results is unsafe.
error_handler	error_handler	No—handlers must never catch themselves.

If the default error_handler itself raises, the run fails. The default handler is never invoked on error-handler nodes, so handler failures cannot recurse.

Functional API

The same timeout= and retry_policy= parameters are available on @task and @entrypoint in the functional API:

from langgraph.func import entrypoint, task
from langgraph.types import RetryPolicy, TimeoutPolicy

@task(
    timeout=TimeoutPolicy(idle_timeout=30),
    retry_policy=RetryPolicy(max_attempts=3),
)
async def call_api(url: str) -> str:
    response = await fetch(url)
    return response.text

@entrypoint(timeout=60)
async def my_workflow(inputs: dict) -> str:
    result = await call_api("https://api.example.com/data")
    return result

The behavior is identical to add_node: NodeTimeoutError is raised on timeout, buffered writes are cleared, and the retry policy decides whether to retry.

Limitations

• Python only: timeouts and error handlers are not available in the JavaScript/TypeScript SDK. Retry policies work in both Python and TypeScript.
• Timeouts are async-only: sync nodes with a timeout are rejected at compile time.
• One handler per node: each node can have at most one error_handler.
• Handler failures bubble up: if the error handler itself raises, that exception propagates as if the node had no handler.

---

Connect these docs to Claude, VSCode, and more via MCP for real-time answers.

Edit this page on GitHub or file an issue.
